Casati ‘Laser Carbon’ Road Frame set. 48cm

Frame size48 cm


Out of stock


Top quality, flagship frame set from Casati. The Monza frame builder has produced some of our favourite frames over the years, and their attention to detail is legendary amongst those in the know. Casati consistently push the boundaries of what is possible with steel frame sets.

This frame features carbon seat- and chain stays bonded to oversized steel front triangle for a lightweight and compliant ride. Carbon head tube inserted within the steel, with small ‘windows’ to reveal the weave. Dedacciai carbon fork with oversized blades and Deda’s proprietary shock reduction system. Internal shifter cables with adjuster barrels at the head tube. Custom bottom bracket shell to accommodate the large, aero chain stays. Replaceable aluminium rear dropouts – Casati branded. 130mm rear spacing, ready to build up with any 8 speed group set. 31.8mm down tube, for clamp-on front derailleur. Includes Casati-branded Selcof carbon seat post, 280mm long and 200g in weight. Provision for two water bottle cages. Finished in bright yellow with clear coat, and visible carbon weave on the fork and rear stays.

  • Seat tube c-c: 48cm
  • Seat tube c-t: 51cm (to lower edge of sloping seat tube)
  • Top tube c-c: 54cm
  • Head tube: 135mm
  • Rear spacing: 130mm
  • Seatpost diameter: 30.0mm
  • Bottom bracket thread: ITA
  • Headset: 1 1/8 threadless
  • Wheel size: 700c

If you are looking for a specific item, please feel free to get in touch – we have a wide range of frames, components and accessories in the shop that are yet to be listed online.
Pickup is welcomed in Berlin.
